sCMOS Sensor 1920×1080 100fps Rolling Shutter & 50fps in Global Shutter:

The new 2.1MP Fairchild Imaging CIS1021 sCMOS sensor simultaneously delivers sensitivity, speed, and dynamic range in a popular 1920×1080 HD format.

BAE Systems Imaging Solutions introduces the latest member of the new scientific CMOS (sCMOS) family which has received an immense response from the imaging market. This new sensor has 6.5 micron square pixels in a 1920×1080 format and is based on the same 5T pixel structure previously released in the Fairchild Imaging CIS2051 sensor. It is available in both a monochrome and a color (Bayer pattern) version.
The Fairchild Imaging CIS1021 is specifically designed for low light imaging applications that require an HD sensor format. Along with its extremely low noise readout and excellent QE, this sensor provides greater than 88dB of intra-scenic dynamic range and produces images at rates up to 100 FPS at full resolution. This unprecedented combination of features makes the CIS1021 ideal for low light scientific imaging applications, fluorescence-based medical diagnostics as well as surveillance and aerial imaging applications.

See Fairchild Imaging for more information.
