Sony Investing 1 Billion Dollars in Stacked CMOS Image Sensors:

Sony announced that it plans to invest $994,400,000 or around 1 Billion dollars in Sony Semiconductor Corporation’s Nagasaki Technology Center (“Nagasaki TEC”) from the first half of the fiscal year ending March 31, 2013 through the first half of the fiscal year ending March 31, 2014, to increase the production capacity for stacked CMOS image sensors.

This investment is intended to provide for new wafer processing equipment for stacked CMOS image sensors, and to increase and transform wafer lines capable of manufacturing CMOS image sensors. With this development, Sony plans to increase total production capacity for CCD and CMOS image sensors to approximately 60,000 wafers per month by the end of September 2013.

In light of the rapidly expanding demand for smartphones and tablets, Sony plans to continue to solidify its leading global position in CMOS image sensors by strengthening its production capabilities for stacked CMOS image sensors, which provide greater performance in a more compact form. Furthermore, Sony intends to accelerate its growth strategy by incorporating superior core technologies, including stacked CMOS image sensors, into a wide range of products for its digital imaging and mobile businesses, which are priorities within its electronics business.

Keep an eye on Sony for more.
